Technology

Standard Compliance
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-T(X) and 100Base-FX
IEEE 802.3ab 1000Base-T
IEEE 802.3af PoE 15.4 Watts
IEEE 802.3at PoE 30 Watts

Interface

Gigabit Ethernet
RJ45 Ports: 1 10/100/1000Base-T PoE+ IN, 1 10/100/1000Base-T DATA OUT, auto MDI/MDI-X, auto negotiation
PoE+ Pinout: PD auto negotiation (1 & 2 DC +, 3 & 6 DC – or 4 & 5 DC +, 7 & 8 DC –)

Power Requirements

PoE+ Input Voltage: 36 to 57 VDC
Output Voltage: 2 sets, 24 VDC redundant terminal block
Output Current: Max. 1.125A
Overload Current Protection: Present, adjust by PoE power classes
Reverse Polarity Protection: Present

Physical

Housing: IP30 metal case
Dimensions : 95 mm(H) x 26.1 mm(W) x 70 mm (D)
Weight : 250g
Installation: DIN-Rail and wall mounting

Environmental Limits

Operating Temperature: -20? to 70?(-4? to 158?)
Storage Temperature: -40? to 85?(-40? to 185?)
Ambient Relative Humidity: 5% to 95%(non-condensing)

Approvals

Safety: EN 60950-1
EMI: FCC 47 CFR Part 15 Subpart B Class A, EN 55022(CISPR 22)
EMS(EN55024): IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11
Shock: IEC 60068-2-27
Freefall: IEC 60068-2-32
Vibration: IEC 60068-2-6
