Technology

Standard Compliance
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-T(X) and 100Base-FX
IEEE 802.3ab 1000Base-T
IEEE 802.3z 1000Base-X
IEEE 802.3x Flow Control
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree Protocol
IEEE 802.1s Multiple Spanning Tree Protocol
IEEE 802.1p Class of Service, Priority Protocols
IEEE 802.1Q VLAN Tagging
IEEE 802.1X Port Authentication
IEEE 802.3ad LACP Aggregation
IEEE 802.1AB Link Layer Discovery Protocol
IEEE 1588v2 Clock Synchronization
IEEE 802.3af PoE 15.4 Watts
IEEE 802.3at PoE 30 Watts

Processing Type

Store and Forward
IEEE 802.3x Flow control in full duplex, back-pressure flow control in half duplex
Interface

Gigabit Ethernet
RJ45 Ports: 8 10/100/1000Base-T, auto MDI/MDI-X, auto negotiation
SFP Ports: 4 100/1000Base-SFP
PoE+ Pinout: 1 & 2 DC +, 3 & 6 DC –
Console Port: RS-232 in RJ45 connector
Alarm Contacts(DO): 1 relay output, Carry current 1 A@24VDC
Reset Button: 1set

Performance and Scalability

Switching Capacity: 24Gbps, Wired speed, Non-blocking switching fabric
Forwarding Rate: 35.7Mpps
MAC Address Table: 8K
Packet Buffer Memory: 4M bits
IGMP Multicast Groups: 256
Max. VLANs: 4096
Quality of Service: 8 priority queues per port
DHCP Server: 253 IP addresses
Jumbo Frame: 9,216 Bytes
