Antenna Characteristics

Wireless Signal: IEEE 802.11 a/b/g/n
Typical application: Indoor / Outdoor
Frequency: 2.4 to 2.5GHz & 4.9 to 5.9GHz
Antenna Type: Omni-directional
Typical Gain: 5.5dBi @ 2.4GHz & 8dBi @ 5GHz
Beam Width: 2.4GHz @ H: 360° / E: 60.1° & 5.8GHz @ H: 360° / E: 21.3°
Polarization: Vertical

Physical Characteristics

Base
Connector: RP-SMA(male) for device, N-type(female) for antenna
Low-Loss Cable Length: 3 meters
Antenna

Connector: N-type(male)
IP Protection: IP65
Radome Material: Fiberglass, UV resistant

Environmental Limits

Operating Temperature: -30? to 60?(-22? to 140?)
Storage Temperature: -40? to 85?(-40? to 185?)
Ambient Relative Humidity: 5% to 95%(non-condensing)
