Network Interface
Transmission method: IEEE 802.3, IEEE 802.3u
Transmission interface: RJ-45 MDI/MDIX, no jumper cable required
Baudrate: 10/100M bps, auto-detection
Network protocols: ICMP, IP, TCP, UDP, DHCP, SMTP, Modbus TCP
Power supply voltage: 24 VDC (-15 to 20%)
Power consumption: 3 W
Insulation voltage: 500 V
RS-485 Interface
Connector 1: RJ-11, 10-pin feed through terminal
Connector 2: 3-pin, removable
Transmission method: RS-485
Serial baudrate: 1,200, 2,400, 4,800, 9,600, 19,200, 38,400, 57,600, 115,200 bps
Data type: Modbus ASCII/RTU, user-defined
