[vc_row][vc_column][vc_tta_tabs][vc_tta_section title=”Features” tab_id=”1505950209507-42fcb17b-817c”][vc_column_text]Programmer, display and controller for transmitters with HART protocol
Highly informative Dot-Matrix display back light
Datalogger memory: Built-in 4 MB Flash memory SD Card slot: max. 2 GB
Tank visualisation
Data Logger
Simple 6-key programming
1 to 15 input channels
Transmitter diagnostic capabilities
Explosion-proof models[/vc_column_text][/vc_tta_section][vc_tta_section title=”Applications” tab_id=”1505950210201-8497d627-a771″][vc_column_text]Programmer, indicator and controller for single transmitters and for transmitter groups
RS485 comm. line with HART or MODBUS protocol[/vc_column_text][/vc_tta_section][/vc_tta_tabs][vc_custom_heading text=”Specifications” font_container=”tag:div|font_size:23|text_align:left|color:%2302026e” use_theme_fonts=”yes”][vc_empty_space height=”20px”][vc_column_text]Power supply: 11,4 – 40 V DC; 11,4 – 28 V AC; 85 – 255 V AC
Ambient temperature: – 20 °C … + 50 °C
Input: HART® transmitters
Outputs, internal: max. 2 4 – 20 mA; max. 2 RS485; max. 5 SPDT relays
Outputs, external: max. 16 4 – 20 mA; max. 2 RS485; max. 64 SPDT relays
Storage medium: SD card (max. 2 GB), Flash memory, USB
Protection: IP65
Approvals: ATEX ex, IEX Ex[/vc_column_text][vc_empty_space height=”30px”][/vc_column][/vc_row]
