[vc_row][vc_column][vc_tta_tabs][vc_tta_section title=”Features” tab_id=”1505949761096-cfb63419-6c9c”][vc_column_text]Piezoresistive silicon or stainless steel sensor
Relative measurement mode
Measurement range downscale
Up to 2 contacts
Aluminium die cast housing
Static overpressure 400 bar
HART® communication versions
High accuracy
Mechanical robust versions
HASTELLOY® sensor version
Ex ia versions*[/vc_column_text][/vc_tta_section][vc_tta_section title=”Applications” tab_id=”1505949761884-b23f31a2-57d3″][vc_column_text]Measurement of pressure difference of gases, compressed air and liquids in closed, pressurized tanks
Plant and machine engineering, HVAC
Chemical industry, energy industry, food and beverage industry
Compact design versions for integration in applications with limited space[/vc_column_text][/vc_tta_section][/vc_tta_tabs][vc_custom_heading text=”Specifications” font_container=”tag:div|font_size:23|text_align:left|color:%2302026e” use_theme_fonts=”yes”][vc_empty_space height=”20px”][vc_column_text]Ambient temperature: – 40 °C … + 85 °C
Process temperature: – 40 °C … + 125 °C
Sensor type: silicon or stainless stee
Pressure: (Nominal pressure gauge) 0 – 70 bar
Output: 4 – 20 mA, 0 – 10V, HART®
Accuracy: 0.075%, 0.1%, 0.5%, 1%
Process connection: ¼”, ½” BSP; ¼”, ½” NPT; M20 x1.5 Ø6,6 x 11 mm (for flex. tubes Ø6); Ø4,45 x 10 mm (for flex. tubes Ø4)
Protection: IP54, IP65, IP67[/vc_column_text][vc_empty_space height=”30px”][/vc_column][/vc_row]
