[vc_row][vc_column][vc_tta_tabs][vc_tta_section title=”Features” tab_id=”1505949092578-184fd7e0-4b6d”][vc_column_text]Silicon, ceramic or stainless steel sensor
Relative or absolute measurement mode
Up to 4 contacts
Rotatable and configurable 4-digit display module
Configurable via PC or programming device
Stainless steel housing versions
Ex ia versions*
Integrated cable version[/vc_column_text][/vc_tta_section][vc_tta_section title=”Applications” tab_id=”1505949093237-15d22a34-c486″][vc_column_text]Gases, steam, liquids, viscous, pasty or highly contaminated media
Pneumatic, hydraulic and mechanical engineering applications
Plant and machine engineering, HVAC, environmental engineering
For rough and difficult installing conditions
Hygienical versions[/vc_column_text][/vc_tta_section][/vc_tta_tabs][vc_custom_heading text=”Specifications” font_container=”tag:div|font_size:23|text_align:left|color:%2302026e” use_theme_fonts=”yes”][vc_empty_space height=”20px”][vc_column_text]Ambient temperature: – 40 °C … + 85 °C
Process temperature: – 40 °C … + 125 °C
Sensor type: silicon, ceramic or stainless steel
Pressure: (Nominal pressure gauge) 0 – 600 bar
Output: 1–2–4 PNP contacts
Accuracy: 0.25%; 0.5% or 1%
Process connection: ?”, ¼”, ½”, ¾”, 1″ 1½”, 2″ or flanges or sanitary
Protection: IP54, IP65, IP67, IP68[/vc_column_text][vc_empty_space height=”30px”][/vc_column][/vc_row]
