[vc_row][vc_column][vc_tta_tabs][vc_tta_section title=”Features” tab_id=”1505948164442-abae7430-1731″][vc_column_text]A or B accuracy class in accordance to EN 60751
Single or dual sensor versions
2- or 4-wire types
Fast response sensor version
Stainless steel probes
Max. 3m probe length
Vibration-resistant version
Thermocouples and RTDs (Resistance Temperature Detectors)
Temperature range up to +600 °C
PFA coated version
Ex versions
IP65 protection[/vc_column_text][/vc_tta_section][vc_tta_section title=”Applications” tab_id=”1505948165148-a51d5447-2908″][vc_column_text]Temperature metering in tanks, tubes, furnaces or boilers
Can be mounted to special technological places
For temperature metering of liquids, vapours, gases
Temperature metering in bearings
Special versions for unique applications[/vc_column_text][/vc_tta_section][/vc_tta_tabs][vc_custom_heading text=”Specifications” font_container=”tag:div|font_size:23|text_align:left|color:%2302026e” use_theme_fonts=”yes”][vc_empty_space height=”20px”][vc_column_text]Ambient temperature: – 20 °C … + 80 °C
Sensor type: “A” or “B” class Pt100
Pressure: max. 25 bar
Measuring range: – 50 °C … + 600 °C
Process connection: M20 x 1,5; ½”; flange
Protection: IP65
Approvals: ATEX ex[/vc_column_text][vc_empty_space height=”30px”][/vc_column][/vc_row]
