[vc_row][vc_column][vc_tta_tabs][vc_tta_section title=”Features” tab_id=”1505950826982-324b9e9d-6786″][vc_column_text]4 – 20mA loop operated
Operation without external power supply
Field display for transmitters
Scalable display
6 digits reflective LCD display
20 mm digit height
4-20 mA to HART converter version
Heavy duty field mountable housing
Stainless steel housing
Explosion-proof models[/vc_column_text][/vc_tta_section][vc_tta_section title=”Applications” tab_id=”1505950827538-fd35f899-1c3c”][vc_column_text]Universal field indicator for any transmitters
Selectable physical parameter set
Display of process values supplied by any transmitter
If used as HART converter, powers 2-wire transmitters[/vc_column_text][/vc_tta_section][/vc_tta_tabs][vc_custom_heading text=”Specifications” font_container=”tag:div|font_size:23|text_align:left|color:%2302026e” use_theme_fonts=”yes”][vc_empty_space height=”20px”][vc_column_text]Power supply: 24 V DC
Ambient temperature: – 40 °C … + 70 °C
Display: 6 digits LCD
Input: 4 – 20 mA
Output: 4 – 20 mA, 4 – 20 mA + HART®
Protection: IP67
Approvals: ATEX ex[/vc_column_text][vc_empty_space height=”30px”][/vc_column][/vc_row]
