[vc_row][vc_column][vc_tta_tabs][vc_tta_section title=”Features” tab_id=”1505950933033-04494f24-cfc1″][vc_column_text]Suitable interface for devices having 4-20 mA or on-off outputs
Can power 2-wire transmitters
Galvanic isolation
4-20 mA input
Power relay (SPDT) output
Limit, differential or window switch capabilities
Programmable damping
Explosion-proof models[/vc_column_text][/vc_tta_section][vc_tta_section title=”Applications” tab_id=”1505950933544-24a0c56a-cc0d”][vc_column_text]Power supply and switching amplifier for 2-wire transmitters
Switching amplifier for 4-wire active transmitters
Dedicated switching amplifier version for the RC-400 range of Ex rated vibrating forks
Wire state monitoring
ON-OFF control[/vc_column_text][/vc_tta_section][/vc_tta_tabs][vc_custom_heading text=”Specifications” font_container=”tag:div|font_size:23|text_align:left|color:%2302026e” use_theme_fonts=”yes”][vc_empty_space height=”20px”][vc_column_text]Power supply: 110 V, 230 V AC, 24 V AC/DC
Ambient temperature: – 10 °C … + 55 °C
Input: 4 – 20 mA
Output: Switch rating: 250 V AC, 8A, AC1
Process connection: DIN rail mounted (module width: 36 mm)
Protection: IP20
Approvals: ATEX ex[/vc_column_text][vc_empty_space height=”30px”][/vc_column][/vc_row]
