Based on IEEE 802.3at standard up to 30Watts per port. Backward compatible with IEEE 802.3af
Dual 10/100/1000Base-T for PoE+ OUT and DATA IN
Intelligent PoE output overvoltage protection
Reverse polarity and overload current protection
Built-in 24VDC power booster for flexible PoE deployment
Dual PoE+ outputs design to supply more devices



Standard Compliance
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-T(X) and 100Base-FX
IEEE 802.3ab 1000Base-T
IEEE 802.3af PoE 15.4 Watts
IEEE 802.3at PoE 30 Watts


Gigabit Ethernet
RJ45 Ports: 2 10/100/1000Base-T PoE+ OUT, 2 10/100/1000Base-T DATA IN, auto MDI/MDI-X, auto negotiation
PoE+ Pinout: 1 & 2 DC +, 3 & 6 DC –

Power Requirements

Input Voltage: 2 sets, 12 to 57 VDC redundant terminal block input
Input Current: 5.5A max. (with powered device)
PoE+ Output Power: Max. 600mA @ 50 VDC, 30 watts per port
Overload Current Protection: Present, max. input current 10A
Reverse Polarity Protection: Present


Housing: IP30 metal case
Dimensions : 95 mm(H) x 41 mm(W) x 70 mm (D)
Weight : 370g
Installation : DIN-Rail and wall mounting

Environmental Limits

Operating Temperature: -20? to 70?(-4? to 158?)
Storage Temperature: -40? to 85?(-40? to 185?)
Ambient Relative Humidity: 5% to 95%(non-condensing)


Safety: EN 60950-1
EMI: FCC 47 CFR Part 15 Subpart B Class A, EN 55022(CISPR 22)
EMS(EN55024): IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11
Shock: IEC 60068-2-27
Freefall: IEC 60068-2-32
Vibration: IEC 60068-2-6
