Supports IPSec, OpenVPN, PPTP, L2TPand GRE standard VPN protocols, CA certificate in IPSec, L2TP over IPSec
Using UMTS/HSPA+ 3G technology, supports a wide range of bands (850 / 800, 900, AWS1700, 1900, 2100 MHz). Downward compatible with GSM/GPRS/EDGE 2G network
Dual SIM redundancy design, seamless switch between two ISP systems for online continuity
HSPA+ data transmission rate up to 21.6Mbps (downlink)/5.76Mbps (uplink)
Automatic APN parameter matching and connection redial
Flexible connection method over WAN port, e.g. static IP, DHCP client and more
Users configurable priorities of the connection to Internet over WAN and 2 cellular networks
Various peripheral interfaces include RS-485, RS-232 and 4 LAN ports
Built-in RTC and supports NTP time synchronization over a network
Firewall functions: Stateful Packet Inspection (SPI), Prevent Denial of Service (DoS) attacks, NAT, port triggering, port mapping, IP address filtering, MAC address filtering, URL filtering
Supports TCP/IP, UDP, ICMP, DHCP, HTTP, DNS and SSH protocols
Device configurations import/export
Network data flow statistics
Networking failure diagnostics
Technology
Standard Compliance
GSM/GPRS/EDGE/ UMTS/HSPA+
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-T(X)
Interface
3G:GSM/GPRS/EDGE/UMTS/HSPA+
Antennas: 1 2.5dBi omni-directional, SMA(male) connector, 3 meters cable with magnetic stand
Fast Ethernet
RJ45 Ports:
WAN: 1 10/100Base-T(X), auto MDI/MDI-X, auto negotiation
LAN: 4 10/100Base-T(X), auto MDI/MDI-X, auto negotiation
Serial Communication
Serial Ports: 1 RS-232( Terminal block), 1 RS-485( Terminal block ), 15KV isolation protection
Baud Rate: 2400bps to 115200bps
Data Bits: 7, 8
Parity: None, Even, Odd
Stop Bits: 1, 2
Flow Control: RTS/CTS(RS-232 only), XON/XOFF
RS-232: TxD, RxD, RTS, CTS, GND
RS-485:D+, D-, GND
SIM Slot
Number of SIMs: 2, Mini-SIM (25mm x 15mm)
SIM Operating Voltage: 1.8V/3V
SD Socket: SDHC(32mm x 24mm x 2.1mm), up to 32GB
Reset Button: 1set
3G RF
Frequency Band
UMTS/HSPA+:800 / 850, 900, AWS1700, 1900, 2100 MHz
GSM/GPRS/EDGE:850, 900, 1800, 1900 MHz
Management
VPN:IPSec, OpenVPN, PPTP, L2TP, GRE
Software: SSH, DNS, HTTP, TFTP, DHCP Server/Client, Syslog, NTP, MODBUS RTU Master, SNMP Server
Security: MAC/IP/URL filtering, SSH, SPI, Prevent denial of service (DoS) attacks, Port triggering, Port mapping
Configuration: Web Browser
Power Requirements
Input Voltage: 12 to 48VDC, 2 pin terminal block input
Input Current: 1A Max.
Overload Current Protection: Present, Max. Input current 1.5A
Reverse Polarity Protection: Present
Physical
Housing: IP30 metal case
Dimensions: 145.3 mm(H) x 45 mm(W) x 112.3 mm (D)
Weight: 372g
Installation: Industrial DIN-Rail and Wall mounting
Environmental Limits
Operating Temperature : -20? to 70?(-4? to 158?)
Storage Temperature: -40? to 85?(-40? to 185?)
Ambient Relative Humidity: 5% to 95%(non-condensing)
Approvals
Safety: UL 60950-1, IEC 60950-1
EMI: FCC 47 CFR Part 15 Subpart B Class B, EN 55022, EN 55032, EN 301 489-1/7/24
EMS( EN 301 489-1/7/24, EN 55024): IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8
RF: EN 301 511, EN 301 908-1; FCC Part 22H, 24E, 27
