A USB/CAN communication converter
Extracts CAN message (incl. standard & extended frames), decodes and displays following DeviceNet and CANopen protocols.
Filters by set conditions
Sends CAN messages, 1 message by manual mode, 8 messages by auto mode
Max. baudrate: 1M bps
A portable USB device


Power supply: No external power supply required
Power consumption: 0.6 W
Insulation voltage: 500 VDC
Baudrate: 10k, 20k, 50k, 100k, 125k, 250k, 500k, 800k, 1M bps
USB connector: A type (plug)
RS-485 terminal: RJ-45 (8-pin)
Dimensions (L×W×H): 3.15×0.89×0.83in (80×22.5×21.2mm)
